型號 modle |
池徑(A) Capacity |
池周邊深（H1） Depth |
周邊線速度 Peripheral line velocity |
驅動功率 Driving |
導流筒∅E Draft tube |
池底坡度 Bottom slope |
| m | m | m/min | KW | m | % | |
| WBZG-3 | 3 | 3.0～4.0 | 2 | 0.55 | 0.8 | 5～8 |
| WBZG-4 | 4 | 3.0～4.0 | 2 | 0.55 | 1 | 5～8 |
| WBZG-5 | 5 | 3.0～4.0 | 2 | 0.55 | 1.2 | 5～8 |
| WBZG-6 | 6 | 3.0～4.0 | 2 | 0.55 | 1.4 | 5～8 |
| WBZG-7 | 7 | 3.0～4.0 | 1.8 | 0.75 | 1.4 | 5～8 |
| WBZG-8 | 8 | 3.0～4.0 | 1.8 | 0.75 | 1.5 | 5～8 |
| WBZG-10 | 10 | 3.0～4.0 | 1.8 | 1.1 | 1.5 | 5～8 |
| WBZG-12 | 12 | 3.0～4.0 | 1.8 | 1.1 | 1.5 | 5～8 |
| WBZG-14 | 14 | 3.0～4.0 | 1.8 | 1.1 | 1.5 | 5～8 |
| WBZG-16 | 16 | 3.0～4.0 | 1.8 | 1.5 | 1.8 | 5～8 |
| WBZG-18 | 18 | 3.0～4.0 | 1.8 | 1.5 | 2 | 5～8 |
| WBZG-20 | 20 | 3.0～4.0 | 1.8 | 1.5 | 2.2 | 5～8 |
